Efficient Machine Learning (ML) Acceleration: create more capable, cost-effective and energy-efficient ML applications.
Advanced Security with EdgeLock® Secure Enclave
Supports all NXP i.MX 93 processor variants
Pin to pin compatible with Eva SoM i.MX 8M Plus
Small dimensions only 40x71mm
230 pin Card Edge connector
Great pin multiplexing flexibility
Ideal for automotive, industrial and consumer IoT market applications
CPU
NXP i.MX 93 Solo\Dual Arm® Cortex®-A55 core
Neural Processing Unit (NPU) option
0.5 TOP/s Neural Network performance
Supports Arm® Cortex®-A55 core frequency up to 1700 MHz
Additional Cortex-M33 Core up to 250 MHz
DRAM MEMORY
Up to 2GB LPDDR4 memory with 16 bit wide Bus
STORAGE / BOOT MEMORY
From 8 to 64 GB eMMC Flash memory
MULTIMEDIA AND HUMAN INTERFACE
Please note that not all the functions may be available simultaneously, due to pin mux limitation of CPU case. We can check if our SoM is compatible with your application, contact us for more information.
Some functions require transceiver or additional circuitry on expansion board.
PXP 2D accelerator
LCDIF display outputs
LVDS display (up to 1366 x 768 or 1280 x 800)
4-lane MIPI-DSI display output
ISI camera interface:
MIPI-CSI input compliant to MIPI-DSI spec v1.2
Image processing for one processed camera stream at 1080p30 or unprocessed camera stream at 2K depending on system load and use case
Audio Interfaces:
S/PDIF Audio Input and output
SAI input / output for external audio codec
I/O PERIPHERALS
Please note that not all the functions may be available simultaneously, due to pin mux limitation of CPU case. We can check if our SoM is compatible with your application, contact us for more information.
Some functions require transceiver or additional circuitry on expansion board.
2 x USB 2.0 OTG
SDIO 3.0 Bus Interface
Up to 5 x UART Interfaces
Up to 2 x LPSPI Interfaces
Up to 4 x I2C Interfaces
Up to 2 x PWM outputs
2 x Ethernet 1Gbps with on-board PHY (optional)
Up to 2 x CAN Bus 2.0B / CAN FD ports
Integrated Secure Element co-processors (optional)
Integrated Temp Sensor (optional)
More GPIOs available & SW configurable (optional)
FRAM (optional)
4 x ADC inputs
SYSTEM
230 pin edge connector
Single +5 VDC ±5% power supply
On board regulators for all integrated functions
Power consumption depends on MPU clock frequency / state.
TEMPERATURE
These temperatures are the ambient operating temperature ranges for the components used into SoM, with exception of iMX 93 processor, which is specified on junction operating temperature range, 0-95°C for commercial version and -40-105°C for industrial version and -40 to 125° for automotive version. SoM ambient operating temperature depends on the application and on the cooling measures applied.
Some ordering options are not available in automotive version. Contact Elettronica GF for more information.
0 to 70°C for commercial version
-40 to 85°C for industrial version
-40 to 105° for automotive version
OPERATING SYSTEMS
Linux (Cortex® – A55 core) + FREERTOS (Cortex® – M33)
Some code combinations are not allowed and others are available on customization only, for more information please contact Elettronica GF sales dept.
